Ridgetop Group’s Prognostic Health Management Solutions

Ridgetop Group excels at employing its Condition-based Maintenance (CBM) solutions through a broad range of sensor arrays that identify, isolate and diagnose degradation and qualification through three specific areas:

  • Electrical
  • Mechanical
  • Electromechanical
  • Structural

Electrical and Electronic CBM+ Solutions

640_mentor-wafer

Through sensor readings and algorithmic data analytics, system data can be processed to provide its state-of-health (SoH) and remaining useful life (RUL). Our proprietary Sentinel Suite software and allow users to properly determine SoH and RUL of subsystems and components such as circuit card assemblies (CCAs), actuators, RF subsystems, power electronics, actuator drive systems and I/O interconnects.

Physical Solutions

Train-HD-WallpapersOur diagnostic solutions extend throughout a number of applications including heavy industrial dual-use applications, diagnosis through profiling air temperature probes on aerospace vehicles, monitoring of rotational, vibrational and temperature parameters, photonics-based detection systems that measure stress and strain (relaying more accurate results than traditional strain gauge-based applications) and detection technology for determining open and shorts on cables quickly in complex cable harnesses.. Most recently, we have developed a Lithium-Ion battery monitoring system for critical aerospace and grid backup applications, providing much needed capacity control for customers.

Model-level Qualification and Reliability Solutions

solder_ballOur Semiconductor Characterization and Testing methods for Qualification and Reliability extend through the semiconductor fabrication process, ranging through wafer-level semiconductor process characterization of intrinsic reliability, analog-to-digital (ADC) converter testing (with easy integration into chip design) to test the converter’s INL and DNL functionality, IDDQ/ISSQ and IDDT module testing for current measurements, interconnect reliability test and qualification for Ball-Grid Array (BGA) using Built-in Self Test (BIST) IP to detect damage to sensitive electronic and electrical interconnects, and high-level process design kit accuracy testing for fabless designers.

Ridgetop’s  Rad-Hard Intellectual Property (IP)

satelliteRidgetop offers design consultation services and products to resolve performance degradation of integrated circuits and modules caused by radiation. Our engineering staff understands the impact caused by harsh environments (including space) through rad-hardened designs that mitigate leakage and threshold voltage shifts in ICs that can cause system failure. Ridgetop offers the ProChek Semiconductor characterization tool as an effective solution to measure radiation effects and degradation using test coupons.

Ridgetop Group Brings Solutions to You

Ridgetop Group products are designed for use by many of today’s most demanding applications and platforms. Our world-class electronic prognostics and semiconductor solutions are used by aerospace, automotive, medical device, industrial, renewable energy, and many more of today’s most demanding industries.

Key product benefits to these applications include:

  • On-going monitoring of equipment SoH
  • Improved reliability of critical electronic systems
  • Reduced downtime
  • Reduced maintenance cost and total ownership costs (TOC)
  • Increased fleet readiness
  • Visibility of system RUL

Ranging from die-level variation analysis tools to radiation-hardened sensors for aerospace applications, Ridgetop products provide the analysis, performance, and reliability you need to keep even the most critical electronic systems healthy.

Figure 3. Ridgetop Family of PHM Solutions

Figure 3. Ridgetop Family of PHM Solutions
